รายละเอียดทางเทคนิค
– Capacity 2000KN
– Measuring range 0 ~ 2000
– Relative error ±1%
– Pressure plate size D295 x T32mm upper plate D295 x T45mm lower plate
– Distance Piece D200 x T50mm x3pcs D200 x T75mm x1pc
– Maximum distance between upper and lower plate 330mm
– Piston stroke 100mm
– Loading speed Around 0.2~10KN/s
– Power supply 220VAC 50HZ 750W
– Dimensions Around 900×400×1000 (L x W x H)
– Net weight Around 780kg
